Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	DiodeType	Voltage-PeakReverse(Max)	Current-Max	Capacitance@VrF	Resistance@IfF	PowerDissipation(Max)	OperatingTemperature
DAP236UT106 RF DIODE STANDARD 35V 150MW UMD3 Rohm Semiconductor	13,364	0.45	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Standard - 1 Pair Common Anode	35V	-	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	150 mW	125°C (TJ)
RN739FT106 RF DIODE PIN 50V 100MW UMD3 Rohm Semiconductor	11,121	0.47	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - 1 Pair Series Connection	50V	50 mA	0.4pF @ 35V, 1MHz	7Ohm @ 10mA, 100MHz	100 mW	125°C (TJ)
1SS390TE61 RF DIODE STANDARD 35V 150MW EMD2 Rohm Semiconductor	456	0.40	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Obsolete	Standard - Single	35V	100 mA	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	150 mW	125°C (TJ)
RN779FT106 RF DIODE PIN 50V UMD3 Rohm Semiconductor	10,439	0.43	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - 1 Pair Series Connection	50V	50 mA	0.9pF @ 35V, 1MHz	7Ohm @ 10mA, 100MHz	-	150°C (TJ)
RN262CST2R RF DIODE PIN 30V 100MW VMN2 Rohm Semiconductor	11,684	0.07	FFQ	Datasheet	Tape & Reel (TR)	-	Active	PIN - Single	30V	100 mA	0.4pF @ 1V, 1MHz	1.5Ohm @ 10mA, 100MHz	100 mW	150°C (TJ)
1SS356VMFHTE-17 35V 1.2PF, UMD2, LOW RF BAND SWI Rohm Semiconductor	14,663	0.45	FFQ		Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	Active	PIN - Single	35V	100 mA	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	-	150°C (TJ)
DAN235UT106 RF DIODE STANDARD 35V 150MW UMD3 Rohm Semiconductor	10,891	0.37	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Standard - 1 Pair Common Cathode	35V	-	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	150 mW	125°C (TJ)
RN141STE61 RF DIODE PIN 50V EMD2 Rohm Semiconductor	2,075	0.40	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Obsolete	PIN - Single	50V	100 mA	0.8pF @ 1V, 1MHz	2Ohm @ 3mA, 100MHz	-	150°C (TJ)
1SS390SMFHT2R BAND SWITCHING DIODES (AEC-Q101 Rohm Semiconductor	12,486	0.41	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	Active	PIN - Single	35V	100 mA	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	-	150°C (TJ)
RN142VMTE-17 60V 100MA, SINGLE, LOW RF PIN DI Rohm Semiconductor	14,187	0.41	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - Single	60V	100 mA	0.45pF @ 1V, 1MHz	3Ohm @ 3mA, 100MHz	-	150°C (TJ)
RN779DT146 RF DIODE PIN 50V SMD3 Rohm Semiconductor	13,479	0.43	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - 1 Pair Series Connection	50V	50 mA	0.9pF @ 35V, 1MHz	7Ohm @ 10mA, 100MHz	-	150°C (TJ)
DAN235ETL RF DIODE STANDARD 35V 150MW EMD3 Rohm Semiconductor	14,190	0.45	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Standard - 1 Pair Common Cathode	35V	-	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	150 mW	125°C (TJ)
1SS390SMT2R BAND SWITCHING DIODES - 1SS390SM Rohm Semiconductor	12,258	0.48	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - Single	35V	100 mA	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	-	150°C (TJ)
RN779FFHT106 RF DIODE PIN 50V UMD3 Rohm Semiconductor	10,884	0.43	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	Active	PIN - 1 Pair Series Connection	50V	50 mA	0.9pF @ 35V, 1MHz	7Ohm @ 10mA, 100MHz	-	150°C (TJ)
DAN235FMFHT106 35V 1.2PF, UMD3, CATHODE COMMON Rohm Semiconductor	11,827	0.00	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	Active	Standard - 1 Pair Common Cathode	35V	-	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	200 mW	150°C (TJ)
1SS356VMTE-17 BAND SWITCHING DIODES : 1SS356VM Rohm Semiconductor	10,218	0.51	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - Single	35V	100 mA	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	-	150°C (TJ)
DAN235FMT106 35V 1.2PF, UMD3, CATHODE COMMON Rohm Semiconductor	10,293	0.00	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	Active	Standard - 1 Pair Common Cathode	35V	-	1.2pF @ 6V, 1MHz	900mOhm @ 2mA, 100MHz	200 mW	150°C (TJ)
RB876WFHTL 5V, 10MA, SERIES CONNECTION, AUT Rohm Semiconductor	13,092	0.79	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	Active	Schottky - 1 Pair Series Connection	5V	10 mA	0.8pF @ 1V, 1MHz	-	-	125°C (TJ)
RN731VTE-17 RF DIODE PIN 50V 100MW UMD2 Rohm Semiconductor	12,814	0.39	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - Single	50V	50 mA	0.4pF @ 35V, 1MHz	7Ohm @ 10mA, 100MHz	100 mW	125°C (TJ)
RN142SMT2R RF DIODE PIN 60V 100MA SOD-523 Rohm Semiconductor	14,239	0.41	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - Single	60V	100 mA	0.45pF @ 1V, 1MHz	2Ohm @ 10mA, 100MHz	-	150°C (TJ)
