Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	DrivenConfiguration	ChannelType	NumberofDrivers	GateType	Voltage-Supply	LogicVoltage-VILVIH	Current-PeakOutput(SourceSink)	InputType	HighSideVoltage-Max(Bootstrap)	Rise/FallTime(Typ)	OperatingTemperature	MountingType
LF2190NTR GATE DRIVER HIGH/LOW SIDE 3.5A IXYS Integrated Circuits Division	9,845	2.06	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Half-Bridge	Independent	2	IGBT, N-Channel MOSFET	10V ~ 20V	0.8V, 2.5V	4.5A, 4.5A	Non-Inverting	600 V	25ns, 20ns	-40°C ~ 125°C (TA)	Surface Mount
IXDN604SIATR IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	6,067	2.21	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	4A, 4A	Non-Inverting	-	9ns, 8ns	-40°C ~ 125°C (TA)	Surface Mount
IXDI604SIATR IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	9,973	2.21	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	4A, 4A	Inverting	-	9ns, 8ns	-40°C ~ 125°C (TA)	Surface Mount
LF2184NTR GATE DRIVER HALF BRIDGE 1.4A IXYS Integrated Circuits Division	7,085	2.37	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Half-Bridge	Independent	2	IGBT, N-Channel MOSFET	10V ~ 20V	0.8V, 2.5V	1.9A, 2.3A	Inverting	600 V	20ns, 40ns	-40°C ~ 125°C (TA)	Surface Mount
IXDN604SITR IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	5,263	3.63	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	4A, 4A	Non-Inverting	-	9ns, 8ns	-40°C ~ 125°C (TA)	Surface Mount
IXDN604SIA IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	8,437	2.21	FFQ	Datasheet	Tube	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	4A, 4A	Non-Inverting	-	9ns, 8ns	-40°C ~ 125°C (TA)	Surface Mount
IXDD604SIA IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	7,836	2.21	FFQ	Datasheet	Tube	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	4A, 4A	Non-Inverting	-	9ns, 8ns	-40°C ~ 125°C (TA)	Surface Mount
IXDD609YI IC GATE DRVR LOW-SIDE TO263 IXYS Integrated Circuits Division	9,591	3.94	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	9A, 9A	Non-Inverting	-	22ns, 15ns	-55°C ~ 150°C (TJ)	Surface Mount
IXDD614CI IC GATE DRVR LOW-SIDE TO220-5 IXYS Integrated Circuits Division	6,606	6.27	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	14A, 14A	Non-Inverting	-	25ns, 18ns	-55°C ~ 150°C (TJ)	Through Hole
IXDI614CI IC GATE DRVR LOW-SIDE TO220-5 IXYS Integrated Circuits Division	7,641	6.27	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	14A, 14A	Inverting	-	25ns, 18ns	-55°C ~ 150°C (TJ)	Through Hole
IXDD630CI IC GATE DRVR LOW-SIDE TO220-5 IXYS Integrated Circuits Division	9,005	9.56	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	12.5V ~ 35V	0.8V, 3.5V	30A, 30A	Non-Inverting	-	11ns, 11ns	-55°C ~ 150°C (TJ)	Through Hole
IXDD630YI IC GATE DRVR LOW-SIDE TO263-5 IXYS Integrated Circuits Division	9,709	9.56	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	12.5V ~ 35V	0.8V, 3.5V	30A, 30A	Non-Inverting	-	11ns, 11ns	-55°C ~ 150°C (TJ)	Surface Mount
IX4310TTR MOSFET DRIVER 2A 24V SOT23 IXYS Integrated Circuits Division	11,558	0.94	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	1	N-Channel, P-Channel MOSFET	4.5V ~ 20V	0.8V, 2.5V	2A, 2A	CMOS, TTL	-	7ns, 7ns	-40°C ~ 125°C (TA)	Surface Mount
IX4428MTR IC GATE DRVR LOW-SIDE 8DFN IXYS Integrated Circuits Division	8,049	1.24	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	N-Channel, P-Channel MOSFET	4.5V ~ 30V	0.8V, 2.4V	1.5A, 1.5A	Inverting, Non-Inverting	-	10ns, 8ns	-55°C ~ 150°C (TJ)	Surface Mount
IXDI609SIATR IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	6,340	2.13	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	9A, 9A	Inverting	-	22ns, 15ns	-55°C ~ 150°C (TJ)	Surface Mount
LF2181NTR GATE DRIVER HIGH/LOW SIDE 1.4A IXYS Integrated Circuits Division	6,699	2.44	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Half-Bridge	Independent	2	IGBT, N-Channel MOSFET	10V ~ 20V	0.8V, 2.5V	1.9A, 2.3A	Non-Inverting	600 V	40ns, 20ns	-40°C ~ 125°C (TA)	Surface Mount
IXDN602SITR IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	8,509	2.63	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	2A, 2A	Non-Inverting	-	7.5ns, 6.5ns	-55°C ~ 150°C (TJ)	Surface Mount
IXDN602PI IC GATE DRVR LOW-SIDE 8DIP IXYS Integrated Circuits Division	8,074	1.71	FFQ	Datasheet	Tube	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	2A, 2A	Non-Inverting	-	7.5ns, 6.5ns	-55°C ~ 150°C (TJ)	Through Hole
IXDF604PI IC GATE DRVR LOW-SIDE 8DIP IXYS Integrated Circuits Division	7,261	2.21	FFQ	Datasheet	Tube	-	Active	Low-Side	Independent	2	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	4A, 4A	Inverting, Non-Inverting	-	9ns, 8ns	-40°C ~ 125°C (TA)	Through Hole
IXDD614SI IC GATE DRVR LOW-SIDE 8SOIC IXYS Integrated Circuits Division	6,103	4.93	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 35V	0.8V, 3V	14A, 14A	Non-Inverting	-	25ns, 18ns	-55°C ~ 150°C (TJ)	Surface Mount
