| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL209678102E3CAP ALUM 1000UF 20% 385V RADIAL |
2,816 | 27.39 |
RFQ |
Datasheet |
Tape & Box (TB) | 096 PLL-4TSI | Active | 1000 µF | ±20% | 385 V | 160mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 5.1 A @ 100 Hz | - | 63 mOhms | 0.787 (20.00mm) | 1.575 Dia (40.00mm) | 2.559 (65.00mm) | - | Through Hole |
|
500C273U063EC2BCAP ALUM 27000UF 63V SCREW |
2,240 | 39.66 |
RFQ |
Datasheet |
Bulk | 500C | Active | 27000 µF | -10%, +75% | 63 V | 14.2mOhm @ 120Hz | 5000 Hrs @ 85°C | -40°C ~ 95°C | Polar | - | General Purpose | 14 A @ 120 Hz | - | - | 0.750 (19.05mm) | 1.750 Dia (44.45mm) | 4.187 (106.35mm) | - | Chassis Mount |
|
|
E32D630HPN563MCD0UCAP ALUM 56000UF 20% 63V SCREW |
1,752 | 27.39 |
RFQ |
Bulk | U32D | Active | 56000 µF | ±20% | 63 V | 6.2mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 26.34 A @ 120 Hz | 29.5008 A @ 50 kHz | - | 0.875 (22.22mm) | 2.000 Dia (50.80mm) | 5.125 (130.18mm) | - | Chassis Mount | |
|
CG273U016V3CCAP ALUM 27000UF 16V SCREW |
1,038 | 39.68 |
RFQ |
Datasheet |
Bulk | CG | Active | 27000 µF | -10%, +75% | 16 V | 12mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 11.4 A @ 120 Hz | 13.11 A @ 10 kHz | - | - | 2.000 Dia (50.80mm) | 3.125 (79.38mm) | - | Chassis Mount |
|
|
E36D750HPN113TDA5UCAP ALUM 11000UF 75V SCREW |
2,936 | 27.42 |
RFQ |
Bulk | U36D | Active | 11000 µF | -10%, +50% | 75 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 1.125 (28.58mm) | 2.500 Dia (63.50mm) | 4.125 (104.78mm) | - | Chassis Mount | |
|
|
E36D451LPN152TCB7UCAP ALUM 1500UF 450V SCREW |
2,568 | 27.43 |
RFQ |
Bulk | U36D | Active | 1500 µF | -10%, +50% | 450 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.875 (22.22mm) | 2.000 Dia (50.80mm) | 4.625 (117.48mm) | - | Chassis Mount | |
|
|
MAL216258153E3CAP ALUM 15000UF 20% 63V SNAP |
3,033 | 27.43 |
RFQ |
Datasheet |
Bulk | 162 PLL-PW | Active | 15000 µF | ±20% | 63 V | 25mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 9.31 A @ 100 Hz | - | 21 mOhms | - | 1.575 Dia (40.00mm) | 4.134 (105.00mm) | - | Through Hole |
|
672D108H7R5ET5JCAP ALUM 1000UF 7.5V RADIAL |
2,459 | 27.43 |
RFQ |
Datasheet |
Bulk | 672D | Active | 1000 µF | - | 7.5 V | - | - | -55°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.417 (36.00mm) | - | Through Hole |
|
|
B43512A0188M000CAP ALUM 1800UF 20% 420V SNAP |
2,197 | 27.43 |
RFQ |
Datasheet |
Bulk | B43512 | Active | 1800 µF | ±20% | 420 V | 70mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 7.12 A @ 100 Hz | - | - | 0.886 (22.50mm) | 1.575 Dia (40.00mm) | 3.819 (97.00mm) | - | Through Hole |
|
MAL250157122E3CAP ALUM 1200UF 20% 450V SCREW |
2,611 | 27.44 |
RFQ |
Datasheet |
Box | 501 PGM-ST | Active | 1200 µF | ±20% | 450 V | 139mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 5.89 A @ 100 Hz | 8.835 A @ 10 kHz | 97 mOhms | 0.874 (22.20mm) | 2.008 Dia (51.00mm) | 3.299 (83.80mm) | - | Chassis Mount |
|
CGO223M016LCAP ALUM 22000UF 20% 16V SCREW |
3,649 | 0.00 |
RFQ |
Datasheet |
Bulk | CGO | Obsolete | 22000 µF | ±20% | 16 V | 10mOhm @ 120Hz | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 11.928 A @ 120 Hz | 14.2 A @ 20 kHz | - | - | 1.375 Dia (34.93mm) | 3.625 (92.08mm) | - | Chassis Mount |
|
|
CGO333M7R5LCAP ALUM 33000UF 20% 7.5V SCREW |
2,800 | 0.00 |
RFQ |
Datasheet |
Bulk | CGO | Obsolete | 33000 µF | ±20% | 7.5 V | 9mOhm @ 120Hz | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 11.928 A @ 120 Hz | 14.2 A @ 20 kHz | - | - | 1.375 Dia (34.93mm) | 3.625 (92.08mm) | - | Chassis Mount |
|
|
LNR2E682MSEBCAP ALUM 6800UF 20% 250V SCREW |
1,462 | 39.77 |
RFQ |
Datasheet |
Bulk | LNR | Active | 6800 µF | ±20% | 250 V | - | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 8.9 A @ 120 Hz | 10.68 A @ 10 kHz | - | 1.126 (28.60mm) | 2.500 Dia (63.50mm) | 4.843 (123.00mm) | - | Chassis Mount |
|
|
LNR2E682MSENCAP ALUM 6800UF 20% 250V SCREW |
2,480 | 39.77 |
RFQ |
Datasheet |
Bulk | LNR | Active | 6800 µF | ±20% | 250 V | - | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 8.9 A @ 120 Hz | 10.68 A @ 10 kHz | - | 1.126 (28.60mm) | 2.500 Dia (63.50mm) | 4.843 (123.00mm) | - | Chassis Mount |
|
|
E36D101LPN532UDA5UCAP ALUM 5300UF 100V SCREW |
3,011 | 27.49 |
RFQ |
Bulk | U36D | Active | 5300 µF | -10%, +75% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 1.125 (28.58mm) | 2.500 Dia (63.50mm) | 4.125 (104.78mm) | - | Chassis Mount | |
|
MAL250019681E3CAP ALUM 680UF 20% 500V SCREW |
2,619 | 27.49 |
RFQ |
Box | 500 PGP-ST | Active | 680 µF | ±20% | 500 V | 308mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3.72 A @ 100 Hz | 5.58 A @ 10 kHz | 275 mOhms | 0.874 (22.20mm) | 2.008 Dia (51.00mm) | 3.299 (83.80mm) | - | Chassis Mount | |
|
|
MAL250059681E3CAP ALUM 680UF 20% 500V SCREW |
3,059 | 27.49 |
RFQ |
Box | 500 PGP-ST | Active | 680 µF | ±20% | 500 V | 308mOhm @ 100Hz | 5000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3.72 A @ 100 Hz | 5.58 A @ 10 kHz | 275 mOhms | 0.874 (22.20mm) | 2.008 Dia (51.00mm) | 3.299 (83.80mm) | - | Chassis Mount | |
|
80LSW15000MEFC51X83CAP ALUM 15000UF 20% 80V SCREW |
2,441 | 42.00 |
RFQ |
Datasheet |
Bulk | LSW | Active | 15000 µF | ±20% | 80 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 7.6 A @ 120 Hz | 8.36 A @ 10 kHz | - | 0.858 (21.80mm) | 2.008 Dia (51.00mm) | 3.386 (86.00mm) | - | Chassis Mount |
|
ALF40C122KP500CAP ALUM 1200UF 20% 500V SNAP |
2,028 | 27.49 |
RFQ |
Datasheet |
Bulk | ALF40 | Active | 1200 µF | ±20% | 500 V | 190mOhm @ 100Hz | 9000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 6.27 A @ 100 Hz | 11 A @ 10 kHz | 160 mOhms | 0.886 (22.50mm) | 1.969 Dia (50.00mm) | 4.213 (107.00mm) | - | Through Hole, Press-Fit |
|
CG742U050U4CCAP ALUM 7400UF 50V SCREW |
1,818 | 39.80 |
RFQ |
Datasheet |
Bulk | CG | Active | 7400 µF | -10%, +75% | 50 V | 22mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 8.7 A @ 120 Hz | 10.005 A @ 10 kHz | - | - | 1.750 Dia (44.45mm) | 4.125 (104.78mm) | - | Chassis Mount |
