| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
860010374011CAP ALUM 330UF 20% 16V RADIAL |
13,052 | 0.24 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATG8 | Active | 330 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 407 mA @ 120 Hz | 561.66 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
860020474011CAP ALUM 180UF 20% 25V RADIAL |
14,950 | 0.24 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATG5 | Active | 180 µF | ±20% | 25 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 210 mA @ 120 Hz | 289.8 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
865090442004CAP ALUM 22UF 20% 25V SMD |
10,596 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-ASLU | Active | 22 µF | ±20% | 25 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 42 mA @ 120 Hz | 63 mA @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.217 (5.50mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
860080374009CAP ALUM 220UF 20% 16V RADIAL |
13,131 | 0.25 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLI | Active | 220 µF | ±20% | 16 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | 575 mA @ 100 kHz | 140 mOhms | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
865230440002CAP ALUM 10UF 20% 25V SMD |
13,866 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-AS5H | Active | 10 µF | ±20% | 25 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 23 mA @ 120 Hz | 34.5 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.217 (5.50mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
860080374008CAP ALUM 180UF 20% 16V RADIAL |
14,937 | 0.25 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLI | Active | 180 µF | ±20% | 16 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | 520 mA @ 100 kHz | 190 mOhms | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
|
860020574009CAP ALUM 120UF 20% 35V RADIAL |
13,087 | 0.25 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATG5 | Active | 120 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 185 mA @ 120 Hz | 255.3 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
865080443005CAP ALUM 27UF 20% 25V SMD |
10,624 | 0.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-ASLI | Active | 27 µF | ±20% | 25 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 130 mA @ 120 Hz | 200 mA @ 100 kHz | 620 mOhms | - | 0.248 Dia (6.30mm) | 0.217 (5.50mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
860160573010CAP ALUM 82UF 20% 35V RADIAL |
13,862 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLL | Active | 82 µF | ±20% | 35 V | - | 4000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 184.08 mA @ 120 Hz | 354 mA @ 100 kHz | 510 mOhms | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.650 (16.50mm) | - | Through Hole |
|
ESK106M100AE3EACAP ALUM 10UF 20% 100V RADIAL |
12,436 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESK | Active | 10 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 75 mA @ 120 Hz | 112.5 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
860010674013CAP ALUM 68UF 20% 50V RADIAL |
10,594 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATG8 | Active | 68 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 220 mA @ 120 Hz | 336.6 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
ESK226M050AC3FACAP ALUM 22UF 20% 50V RADIAL |
10,662 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESK | Active | 22 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 100 mA @ 120 Hz | 150 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
865080343007CAP ALUM 56UF 20% 16V SMD |
11,528 | 0.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-ASLI | Active | 56 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 143 mA @ 120 Hz | 220 mA @ 100 kHz | 560 mOhms | - | 0.248 Dia (6.30mm) | 0.217 (5.50mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
860160373014CAP ALUM 180UF 20% 16V RADIAL |
10,654 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLL | Active | 180 µF | ±20% | 16 V | - | 4000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 243.6 mA @ 120 Hz | 420 mA @ 100 kHz | 560 mOhms | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.689 (17.50mm) | - | Through Hole |
|
|
860160373016CAP ALUM 220UF 20% 16V RADIAL |
13,689 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLL | Active | 220 µF | ±20% | 16 V | - | 4000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 292.32 mA @ 120 Hz | 504 mA @ 100 kHz | 520 mOhms | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.650 (16.50mm) | - | Through Hole |
|
860130873002CAP ALUM 1UF 20% 100V RADIAL |
11,481 | 0.26 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATET | Active | 1 µF | ±20% | 100 V | - | 1000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 24 mA @ 120 Hz | 40.8 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
ESH107M6R3AC3AACAP ALUM 100UF 20% 6.3V RADIAL |
11,338 | 0.23 |
RFQ |
Datasheet |
Bulk | ESH | Active | 100 µF | ±20% | 6.3 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 100 mA @ 120 Hz | 150 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
865090443005CAP ALUM 33UF 20% 25V SMD |
12,247 | 0.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-ASLU | Active | 33 µF | ±20% | 25 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 52 mA @ 120 Hz | 78 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.217 (5.50mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
865090142005CAP ALUM 100UF 20% 6.3V SMD |
12,223 | 0.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-ASLU | Active | 100 µF | ±20% | 6.3 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 70 mA @ 120 Hz | 105 mA @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.217 (5.50mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
|
860020274013CAP ALUM 680UF 20% 10V RADIAL |
14,373 | 0.27 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATG5 | Active | 680 µF | ±20% | 10 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 365 mA @ 120 Hz | 503.7 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
