Mfr. Part #	Availability	Quantity	Datasheet	Packaging	Series	ProductStatus	DiodeType	Voltage-PeakReverse(Max)	Current-Max	Capacitance@VrF	Resistance@IfF	PowerDissipation(Max)	OperatingTemperature
HSMP-389F-BLKG RF DIODE PIN 100V SOT323 Broadcom Limited	3,801	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 1 Pair Common Cathode	100V	1 A	0.3pF @ 5V, 1MHz	2.5Ohm @ 5mA, 100MHz	-	150°C (TJ)
HSMP-3814-BLKG RF DIODE PIN 100V SOT23-3 Broadcom Limited	3,484	RFQ	Datasheet	Strip	-	Obsolete	PIN - 1 Pair Common Cathode	100V	1 A	0.35pF @ 50V, 1MHz	3Ohm @ 100mA, 100MHz	-	150°C (TJ)
HSMP-389C-BLKG RF DIODE PIN 100V SOT323 Broadcom Limited	2,018	RFQ	Datasheet	Strip	-	Obsolete	PIN - 1 Pair Series Connection	100V	1 A	0.3pF @ 5V, 1MHz	2.5Ohm @ 5mA, 100MHz	-	150°C (TJ)
HSMP-3813-BLKG RF DIODE PIN 100V SOT23-3 Broadcom Limited	3,639	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 1 Pair Common Anode	100V	1 A	0.35pF @ 50V, 1MHz	3Ohm @ 100mA, 100MHz	-	150°C (TJ)
HSMP-3812-BLKG RF DIODE PIN 100V SOT23-3 Broadcom Limited	2,139	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 1 Pair Series Connection	100V	1 A	0.35pF @ 50V, 1MHz	3Ohm @ 100mA, 100MHz	-	150°C (TJ)
HSMS-282F-TR2G RF DIODE SCHOTTKY 15V SOT323 Broadcom Limited	3,778	RFQ	Datasheet	Bulk	-	Obsolete	Schottky - 1 Pair Common Cathode	15V	1 A	1pF @ 0V, 1MHz	12Ohm @ 5mA, 1MHz	-	150°C (TJ)
HSMP-389E-BLKG RF DIODE PIN 100V SOT323 Broadcom Limited	2,475	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 1 Pair Common Anode	100V	1 A	0.3pF @ 5V, 1MHz	2.5Ohm @ 5mA, 100MHz	-	150°C (TJ)
HSMP-389V-BLKG RF DIODE PIN 100V SOT363 Broadcom Limited	3,041	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 2 Independent	100V	1 A	0.3pF @ 5V, 1MHz	2.5Ohm @ 5mA, 100MHz	-	150°C (TJ)
HSMS-280C-BLKG RF DIODE SCHOTTKY 70V SOT323 Broadcom Limited	3,780	RFQ	Datasheet	Bulk	-	Obsolete	Schottky - 1 Pair Series Connection	70V	1 A	2pF @ 0V, 1MHz	35Ohm @ 5mA, 1MHz	-	150°C (TJ)
HSMS-280F-BLKG RF DIODE SCHOTTKY 70V SOT323 Broadcom Limited	3,774	RFQ	Datasheet	Bulk	-	Obsolete	Schottky - 1 Pair Common Cathode	70V	1 A	2pF @ 0V, 1MHz	35Ohm @ 5mA, 1MHz	-	150°C (TJ)
HSMS-2814-BLKG RF DIODE SCHOTTKY 20V SOT23-3 Broadcom Limited	3,533	RFQ	Datasheet	Bulk	-	Obsolete	Schottky - 1 Pair Common Cathode	20V	1 A	1.2pF @ 0V, 1MHz	15Ohm @ 5mA, 1MHz	-	150°C (TJ)
HSMP-4820-BLKG RF DIODE PIN 50V SOT23-3 Broadcom Limited	2,344	RFQ	Datasheet	Strip	-	Obsolete	PIN - Single	50V	1 A	0.75pF @ 20V, 1MHz	600mOhm @ 10mA, 1MHz	-	150°C (TJ)
HSMS-2815-BLKG RF DIODE SCHOTTKY 20V SOT143-4 Broadcom Limited	3,119	RFQ	Datasheet	Bulk	-	Obsolete	Schottky - 2 Independent	20V	1 A	1.2pF @ 0V, 1MHz	15Ohm @ 5mA, 1MHz	-	150°C (TJ)
HSMS-2813-BLKG RF DIODE SCHOTTKY 20V SOT23-3 Broadcom Limited	2,563	RFQ	Datasheet	Strip	-	Obsolete	Schottky - 1 Pair Common Anode	20V	1 A	1.2pF @ 0V, 1MHz	15Ohm @ 5mA, 1MHz	-	150°C (TJ)
HSMP-381E-BLKG RF DIODE PIN 100V SOT323 Broadcom Limited	3,460	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 1 Pair Common Anode	100V	1 A	0.35pF @ 50V, 1MHz	3Ohm @ 100mA, 100MHz	-	150°C (TJ)
HSMP-381C-BLKG RF DIODE PIN 100V SOT323 Broadcom Limited	3,610	RFQ	Datasheet	Strip	-	Obsolete	PIN - 1 Pair Series Connection	100V	1 A	0.35pF @ 50V, 1MHz	3Ohm @ 100mA, 100MHz	-	150°C (TJ)
HSMP-3895-BLKG RF DIODE PIN 100V SOT143-4 Broadcom Limited	3,671	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 2 Independent	100V	1 A	0.3pF @ 5V, 1MHz	2.5Ohm @ 5mA, 100MHz	-	150°C (TJ)
HSMP-381F-BLKG RF DIODE PIN 100V SOT323 Broadcom Limited	3,523	RFQ	Datasheet	Bulk	-	Obsolete	PIN - 1 Pair Common Cathode	100V	1 A	0.35pF @ 50V, 1MHz	3Ohm @ 100mA, 100MHz	-	150°C (TJ)
HMPP-3862-BLK RF DIODE PIN 50V MINIPAK Broadcom Limited	2,603	RFQ		Bulk	-	Obsolete	PIN - 2 Independent	50V	1 A	0.2pF @ 50V, 1MHz	22Ohm @ 1mA, 100MHz	-	150°C (TJ)
HMPS-2822-BLK RF DIODE SCHOTTKY 15V MINIPAK Broadcom Limited	2,446	RFQ	Datasheet	Bulk	-	Obsolete	Schottky - 2 Independent	15V	1 A	1pF @ 0V, 1MHz	12Ohm @ 5mA, 1MHz	-	150°C (TJ)
