Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
E22/6/16/R-3C95-A160-P PLANAR E CORES Ferroxcube	12,245	0.75	RFQ	Datasheet	Bulk	-	Active	E	E 22 x 6 x 16	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
RM6S/I-3C96-A100 RM CORES 2PC SET Ferroxcube	13,340	0.75	RFQ	Datasheet	Bulk	-	Active	RM	RM 6	3C96	-	100 nH	±3%	Gapped	63	-	0.784	29.2	37	31.2	1090	Uncoated	0.488 (12.40mm)
RM6S/I-3C96-A160 RM CORES 2PC SET Ferroxcube	14,964	0.75	RFQ	Datasheet	Bulk	-	Active	RM	RM 6	3C96	-	160 nH	±3%	Gapped	100	-	0.784	29.2	37	31.2	1090	Uncoated	0.488 (12.40mm)
EC35/17/10-3C91 EC CORES Ferroxcube	14,801	0.75	RFQ	Datasheet	Bulk	-	Active	EC	EC 35 x 17 x 10	3C91	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.681 (17.30mm)
B65839A0040A033 FERRITE CORE EPCOS - TDK Electronics	14,116	0.75	RFQ	Datasheet	Box	EP7	Active	EP	EP 7	M33	-	-	-	Gapped	-	750	1.52	15.7	10.3	8.5	162	Uncoated	0.148 (3.75mm)
B66337G0100X127 FERRITE CORE EC N27 1PC EPCOS - TDK Electronics	11,175	0.75	RFQ	Datasheet	Box	B66337	Not For New Designs	EC	EC 35 x 17 x 10	N27	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.687 (17.45mm)
E36/21/12-3C94 FERRITE CORE Ferroxcube	13,528	0.75	RFQ	Datasheet	Bulk	-	Active	E	E 36 x 21 x 12	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.856 (21.75mm)
RM6S/I-3C95-A100 RM CORES 2PC SET Ferroxcube	14,115	0.75	RFQ	Datasheet	Bulk	-	Active	RM	RM 6	3C95	-	100 nH	±3%	Gapped	63	-	0.784	29.2	37	31.2	1090	Uncoated	0.488 (12.40mm)
RM6S/I-3C95-A160 RM CORES 2PC SET Ferroxcube	14,994	0.75	RFQ	Datasheet	Bulk	-	Active	RM	RM 6	3C95	-	160 nH	±3%	Gapped	100	-	0.784	29.2	37	31.2	1090	Uncoated	0.488 (12.40mm)
6598170121 98 EP CORE SET Fair-Rite Products Corp.	12,622	0.75	RFQ	Datasheet	Bulk	-	Active	EP	-	-	-	-	±25%	Ungapped	-	2400	80	26.8	33.6	25.2	899	Uncoated	-
B65931J0000X022 FERRITE CORES EPCOS - TDK Electronics	13,130	0.75	RFQ		Box	PS5.6/1.7	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
E35/18/10-3F36 E CORES Ferroxcube	12,785	0.75	RFQ	Datasheet	Bulk	-	Active	E	E 35 x 18 x 10	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.689 (17.50mm)
B65859A0000R057 FERRITE CORE EPX 2UH T57 2PCS EPCOS - TDK Electronics	14,534	0.76	RFQ	Datasheet	Box	EPX10	Active	EPX	EPX 10	T57	-	2 µH	-20%, +30%	Ungapped	2170	4000	1.37	21.7	15.9	13.2	345	Uncoated	0.205 (5.20mm)
B66319G0000X135 FERRITE CORE EPCOS - TDK Electronics	14,315	0.76	RFQ	Datasheet	Box	E30/15/7	Active	E	E 30 x 15 x 7	T35	-	-	-	-	-	6000	1.12	67	60	49	4000	Uncoated	0.598 (15.20mm)
B65517W0000R087 FERRITE CORE EPCOS - TDK Electronics	12,976	0.76	RFQ	Datasheet	Box	P9/5	Active	-	P 9 x 5	N87	0.366 (9.30mm)	-	-	-	-	2200	1.13	13.4	11.9	9.3	159	Uncoated	0.106 (2.70mm)
B66421U0090A197 FERRITE CORE EPCOS - TDK Electronics	11,934	0.76	RFQ	Datasheet	Box	EFD25/13/9	Active	EFD	EFD 25 x 13 x 9	N97	-	-	-	Gapped	-	2300	0.98	57	58	57	3310	Uncoated	0.492 (12.50mm)
EP5-3F46 EP AND EPX CORES 2PC SET Ferroxcube	10,743	0.76	RFQ	Datasheet	Bulk	-	Active	EP	EP 5	3F46	-	-	±25%	Ungapped	-	-	3.2	9.7	3	2.27	28.7	Uncoated	0.220 (5.60mm)
EPX10-3C96 EP AND EPX CORES 2PC SET Ferroxcube	12,912	0.76	RFQ	Datasheet	Bulk	-	Active	EPX	EPX 10	3C96	-	-	±25%	Ungapped	-	-	1.45	21.7	15	12.5	325	Uncoated	0.421 (10.40mm)
E22/6/16/R-3C97-A250-P PLANAR E CORES Ferroxcube	12,332	0.76	RFQ	Datasheet	Bulk	-	Active	E	E 22 x 6 x 16	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
E22/6/16/R-3C97-A400-P PLANAR E CORES Ferroxcube	12,925	0.76	RFQ	Datasheet	Bulk	-	Active	E	E 22 x 6 x 16	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
