Results:

Mfr. Part #	Availability	Quantity	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
PC44HRMD7-E33606C MN FERRITE TDK Corporation	12,202	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PC40RM6Z-12-NN MN FERRITE TDK Corporation	13,141	RFQ	Bulk	RM	Last Time Buy	RM	RM 6	PC40	-	1.6 µH	-	Ungapped	1520	2300	0.78	28.6	36.6	30.2	1050	Uncoated	0.244 (6.20mm)
PC40P22/13Z-52H-NN MN FERRITE TDK Corporation	14,098	RFQ	Bulk	P	Last Time Buy	P	P 22 x 13	PC40	0.850 (21.60mm)	2.99 µH	-	Ungapped	1182	2300	0.497	31.5	63.4	47.7	1997	Uncoated	0.268 (6.80mm)
H5C3RM6Z-12 MN FERRITE TDK Corporation	11,071	RFQ	Bulk	RM	Last Time Buy	RM	RM 6	H5C3	-	9.1 µH	-	Ungapped	5648	15000	0.781	28.6	36.6	30.2	1050	Uncoated	0.244 (6.20mm)
HS52T14X7X8E MN FERRITE TDK Corporation	13,061	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PC44HRM6/6-E33610C-N MN FERRITE TDK Corporation	12,090	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PC40P7/4A160-52S MN FERRITE TDK Corporation	11,270	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
H5A EP10-Z MN FERRITE TDK Corporation	10,081	RFQ	Bulk	EP	Last Time Buy	EP	EP 10	-	-	1.08 µH	-	Ungapped	1461	-	1.7	19.2	11.3	7.79	217	-	0.205 (5.20mm)
PC40HRM6/5.4-A83 MN FERRITE TDK Corporation	11,595	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
H5AP7/4Z-52S MN FERRITE TDK Corporation	12,734	RFQ	Bulk	P	Last Time Buy	P	P 7 x 4	H5A	0.289 (7.35mm)	1.2 µH	±25%	Ungapped	1366	3300	1.43	10	7	5.57	70	Uncoated	0.083 (2.10mm)
H5AT28X13X16E MN FERRITE TDK Corporation	13,885	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
H5ARM6Z-12 MN FERRITE TDK Corporation	11,222	RFQ	Bulk	RM	Last Time Buy	RM	RM 6	H5A	-	3.3 µH	±25%	Ungapped	2258	3300	0.781	28.6	36.6	30.2	1050	Uncoated	0.244 (6.20mm)
PC40HRM6/5.4-Z MN FERRITE TDK Corporation	14,455	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PC44HRM7/6.9E33802-N MN FERRITE TDK Corporation	13,611	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
H5C3T4X1X2P MN FERRITE TDK Corporation	14,688	RFQ	Bulk	T	Last Time Buy	Toroid	-	H5C3	0.157 (4.00mm)	2 µH	±30%	Ungapped	-	15000	9.06	8.71	0.961	-	8.37	Coated	0.039 (1.00mm)
PC40P9/5A160-52H MN FERRITE TDK Corporation	12,608	RFQ	Bulk	P	Last Time Buy	P	P 9 x 5	PC40	0.366 (9.30mm)	160 nH	±5%	Gapped	160	2300	1.24	12.4	10	7.29	124	Uncoated	0.106 (2.70mm)
PC44HRMD7-E33606B MN FERRITE TDK Corporation	13,979	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
H5AT14X3.5X7E MN FERRITE TDK Corporation	12,071	RFQ	Bulk	T	Last Time Buy	Toroid	-	H5A	0.551 (14.00mm)	1.65 µH	±25%	Ungapped	-	3300	2.59	30.5	11.8	-	360	Epoxy	0.138 (3.50mm)
PC44HRMD7-E33606D-N MN FERRITE TDK Corporation	13,417	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
HS52T18X10X10E MN FERRITE TDK Corporation	10,872	RFQ	Bulk	-	Last Time Buy	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
