Results:

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B65981Q0400K095 PQ50/50-N95-DG400 EPCOS - TDK Electronics	1,716	27.60	RFQ	Datasheet	Bulk	PQ50/50	Active	PQ	PQ 50 x 50	N95	-	400 nH	±10%	Distributed Gapped	-	3000	0.342	113	332	314	37630	Uncoated	0.984 (25.00mm)
5978015901 78 TOROID Fair-Rite Products Corp.	2,627	35.01	RFQ	Datasheet	Tray	-	Active	Toroid	-	78	-	-	±25%	Ungapped	-	2300	-	230	277	-	63700	Uncoated	0.500 (12.70mm)
5978014001 78 TOROID Fair-Rite Products Corp.	2,989	42.02	RFQ	Datasheet	Bulk	-	Active	Toroid	-	78	-	-	±25%	Ungapped	-	2300	-	274	324	-	88700	Uncoated	-
TX107/65/18-3E27 FERRITE CORES ROUND Ferroxcube	2,064	54.06	RFQ	Datasheet	Bulk	-	Active	Toroid	TX 107 x 65 x 18	3E27	4.228 (107.40mm)	-	-	-	-	-	-	-	-	-	-	Epoxy	0.720 (18.30mm)
B65982Q0400K097 PQ65/60-N97-DG400 EPCOS - TDK Electronics	4,354	55.48	RFQ	Datasheet	Tray	PQ65/60	Active	PQ	PQ 65 x 60	N97	-	400 nH	±10%	Distributed Gapped	-	-	0.228	137	171	531	81950	Uncoated	1.181 (30.00mm)
B65982Q0250K097 PQ65/60-N97-DG250 EPCOS - TDK Electronics	2,579	55.48	RFQ	Datasheet	Tray	PQ65/60	Active	PQ	PQ 65 x 60	N97	-	250 nH	±10%	Distributed Gapped	-	-	0.228	137	171	531	81950	Uncoated	1.181 (30.00mm)
B65982Q0100K095 PQ65/60-N95-DG100 EPCOS - TDK Electronics	2,833	72.92	RFQ	Datasheet	Bulk	PQ65/60	Active	PQ	PQ 65 x 60	N95	-	100 nH	±10%	Distributed Gapped	-	3000	0.228	137	171	531	81950	Uncoated	1.181 (30.00mm)
B65982Q0250K095 PQ65/60-N95-DG250 EPCOS - TDK Electronics	1,430	72.92	RFQ	Datasheet	Bulk	PQ65/60	Active	PQ	PQ 65 x 60	N95	-	250 nH	±10%	Distributed Gapped	-	3000	0.228	137	171	531	81950	Uncoated	1.181 (30.00mm)
B65982Q0400K095 PQ65/60-N95-DG400 EPCOS - TDK Electronics	1,650	72.92	RFQ	Datasheet	Bulk	PQ65/60	Active	PQ	PQ 65 x 60	N95	-	400 nH	±10%	Distributed Gapped	-	3000	0.228	137	171	531	81950	Uncoated	1.181 (30.00mm)
5978008001 78 TOROID Fair-Rite Products Corp.	321	111.44	RFQ	Datasheet	Bulk	-	Active	Toroid	-	78	-	-	±25%	Ungapped	-	2300	-	313	760	-	237000	Uncoated	0.750 (19.05mm)
35T0135-60P FERRITE CORE TOROID 3.45MM OD Laird-Signal Integrity Products	14,243	0.10	RFQ	Datasheet	Bulk	-	Active	Toroid	-	35	0.140 (3.56mm)	1.001 µH	±20%	Ungapped	-	5000	6.277	7.619	1.214	-	9.248	Parylene	0.060 (1.52mm)
28T0119-00P FERRITE CORE TOROID 3.07MM OD Laird-Signal Integrity Products	11,977	0.10	RFQ	Datasheet	Bulk	-	Active	Toroid	-	28	0.120 (3.05mm)	189 nH	±20%	Ungapped	-	850	5.651	5.988	1.06	-	6.345	Parylene	0.050 (1.27mm)
35T0119-00P FERRITE CORE TOROID 3.07MM OD Laird-Signal Integrity Products	12,159	0.10	RFQ	Datasheet	Bulk	-	Active	Toroid	-	35	0.120 (3.05mm)	1.112 µH	±20%	Ungapped	-	5000	5.651	5.988	1.06	-	6.345	Parylene	0.050 (1.27mm)
25T0135-60P FERRITE CORE TOROID 3.45MM OD Laird-Signal Integrity Products	14,864	0.10	RFQ	Datasheet	Bulk	-	Active	Toroid	-	25	0.135 (3.43mm)	25 nH	±30%	Ungapped	-	125	6.277	7.619	1.214	-	9.248	Parylene	0.060 (1.52mm)
35T0155-00P FERRITE CORE TOROID 3.96MM OD Laird-Signal Integrity Products	12,841	0.10	RFQ	Datasheet	Bulk	-	Active	Toroid	-	35	0.155 (3.94mm)	-	±20%	Ungapped	-	5000	4.194	9.165	2.185	-	20.029	Parylene	0.100 (2.54mm)
36T0153-30P FERRITE CORE TOROID 3.96MM OD Laird-Signal Integrity Products	14,615	0.16	RFQ	Datasheet	Bulk	-	Active	Toroid	-	36	0.160 (4.06mm)	-	±25%	Ungapped	-	4500	2.563	8.054	3.142	-	25.309	Parylene	0.120 (3.05mm)
B65885A0000R092 FERRITE CORE PQ 1.9UH N92 2PCS EPCOS - TDK Electronics	8,075	2.73	RFQ	Datasheet	Box	PQ16/11.6	Active	PQ	PQ 16 x 11.6	N92	-	1.9 µH	-20%, +30%	Ungapped	970	1500	0.641	27	42.1	38.5	1136	Uncoated	0.228 (5.80mm)
UR35/27.5/13-3C90 UR CORES Ferroxcube	8,154	2.73	RFQ	Datasheet	Bulk	-	Active	UR	UR 35 x 27.5 x 13	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	1.083 (27.50mm)
RM7/I-3F36-A250 RM CORES 2PC SET Ferroxcube	6,547	2.75	RFQ	Datasheet	Bulk	-	Active	RM	RM 7	3F36	-	250 nH	±3%	Gapped	135	-	0.68	30	44.1	39.6	1325	Uncoated	0.528 (13.40mm)
B65805C0315A048 FERRITE CORE RM 315NH N48 2PCS EPCOS - TDK Electronics	8,273	2.83	RFQ	Datasheet	Cut Tape (CT),Tape & Box (TB)	RM5	Active	RM	RM 5	N48	-	315 nH	±3%	Gapped	251	-	1	20.8	20.8	-	433	Uncoated	0.207 (5.25mm)
