Film Capacitors

Manufacturer	Package/Case	Packaging	Series	ProductStatus	Capacitance	Tolerance	VoltageRating-AC	VoltageRating-DC	DielectricMaterial	ESR(EquivalentSeriesResistance)	OperatingTemperature	MountingType	Size/Dimension	Height-Seated(Max)	Termination	LeadSpacing	Applications	Ratings

Reset All

Apply All

Results:

Mfr. Part #	Availability	Price	Quantity	Datasheet	Package/Case	Packaging	Series	ProductStatus	Capacitance	Tolerance	VoltageRating-AC	VoltageRating-DC	DielectricMaterial	ESR(EquivalentSeriesResistance)	OperatingTemperature	MountingType	Size/Dimension	Height-Seated(Max)	Termination	LeadSpacing	Applications	Ratings
SNU102K504R-F CAP FILM 0.5UF 10% 1KVPK RADIAL Cornell Dubilier Electronics (CDE)	1,296	55.83	RFQ	Datasheet	Radial, Can	Bulk	SNU	Active	0.5 µF	±10%	1000Vpk (1KVPK)	-	Paper, Metallized	-	-50°C ~ 70°C	Chassis Mount	2.100 L x 1.810 W (53.34mm x 45.97mm)	2.134 (54.20mm)	Solder Lug	0.810 (20.57mm)	High Pulse, DV/DT; Snubber	-
B25620B1706K981 CAP FILM 70UF 10% 1.98KVDC RAD EPCOS - TDK Electronics	4,282	55.98	RFQ	Datasheet	Radial, Can	Bulk	MKP DC Link	Active	70 µF	±10%	-	1980V (1.98kV)	Polypropylene (PP), Metallized	-	-55°C ~ 85°C	Chassis, Stud Mount	3.346 Dia (85.00mm)	4.055 (103.00mm)	Threaded, Female	1.260 (32.00mm)	DC Link, DC Filtering	-
UNL8W40K-F CAP FILM 40UF 10% 800VDC RADIAL Cornell Dubilier Electronics (CDE)	4,523	64.59	RFQ	Datasheet	Radial	Bulk,Bulk	UNL	Active	40 µF	±10%	-	800V	Polypropylene (PP), Metallized	7.5 mOhms	-55°C ~ 105°C	Through Hole	1.969 Dia (50.00mm)	2.500 (63.50mm)	PC Pins	0.500 (12.70mm)	DC Link, DC Filtering	-
C44PRGR5220RASK CAP FILM 22UF 10% 1.4KVDC RADIAL KEMET	4,768	56.20	RFQ	Datasheet	Radial, Can	Bulk	C44P-R	Active	22 µF	±10%	640V	1400V (1.4kV)	Polypropylene (PP), Metallized	-	-25°C ~ 70°C	Chassis, Stud Mount	2.559 Dia (65.00mm)	5.866 (149.00mm)	Threaded, Male	1.102 (28.00mm)	Power Factor Correction (PFC); Commutation; EMI, RFI Suppression	-
944U660K102AAI CAP FILM 66UF 10% 1KVDC RADIAL Cornell Dubilier Electronics (CDE)	1,271	56.21	RFQ	Datasheet	Radial, Can	Bulk	944U	Active	66 µF	±10%	-	1000V (1kV)	Polypropylene (PP), Metallized	0.6 mOhms	-40°C ~ 85°C	Chassis Mount	3.327 Dia (84.50mm)	1.614 (41.00mm)	Threaded, Female	1.772 (45.00mm)	DC Link, DC Filtering	-
SNU202K254R-F CAP FILM 0.25UF 10% 2KVPK RADIAL Cornell Dubilier Electronics (CDE)	3,051	56.54	RFQ	Datasheet	Radial, Can	Bulk	SNU	Active	0.25 µF	±10%	2000Vpk (2KVPK)	-	Paper, Metallized	-	-50°C ~ 70°C	Chassis Mount	2.100 L x 1.810 W (53.34mm x 45.97mm)	2.134 (54.20mm)	Solder Lug	0.810 (20.57mm)	High Pulse, DV/DT; Snubber	-
B32373A5107J530 CAP FILM 100UF 5% 1.35KVDC RAD EPCOS - TDK Electronics	2,445	56.76	RFQ		Radial, Can	Bulk	MKD AC - Single Phase	Active	100 µF	±5%	530V	1350V (1.35kV)	Polypropylene (PP), Metallized	-	-40°C ~ 70°C	Chassis, Stud Mount	3.780 Dia (96.00mm)	5.807 (147.50mm)	Threaded, Male	1.378 (35.00mm)	General Purpose	-
OTBF126KNPIR-F CAP FILM 12UF 10% 600VDC RADIAL Cornell Dubilier Electronics (CDE)	2,071	56.79	RFQ	Datasheet	Radial, Can	Bulk	OTB	Active	12 µF	±10%	330V	600V	Paper, Metallized	-	-55°C ~ 85°C	Chassis Mount, Requires Holder/Bracket	2.910 L x 1.910 W (73.91mm x 48.51mm), Lip	4.000 (101.60mm)	Solder Lug	0.810 (20.57mm)	DC Link, DC Filtering; Motor Run	-
B32373A5137J300 CAP FILM 133UF 5% 500VAC RADIAL EPCOS - TDK Electronics	2,022	57.00	RFQ	Datasheet	Radial, Can	Bulk	MKD AC - Single Phase	Active	133 µF	±5%	500V	-	Polypropylene (PP), Metallized	-	-40°C ~ 70°C	Chassis, Stud Mount	-	-	Threaded, Male	-	General Purpose	-
B25690A1427K101 CAP FILM 420UF 10% 1.1KVDC RAD EPCOS - TDK Electronics	2,896	57.15	RFQ	Datasheet	Radial, Can	Bulk	MKP DC Link - Resin Top	Discontinued at Mosen	420 µF	±10%	-	1100V (1.1kV)	Polypropylene (PP), Metallized	2.4 mOhms	-40°C ~ 85°C	Chassis Mount	3.346 Dia (85.00mm)	5.591 (142.00mm)	Threaded, Female	1.260 (32.00mm)	General Purpose	-
MKP1848C71290JY5 CAP FILM 120UF 5% 900VDC RADIAL Vishay Beyschlag/Draloric/BC Components	3,414	57.37	RFQ	Datasheet	Radial - 4 Leads	Bulk	MKP1848C DC-Link	Active	120 µF	±5%	-	900V	Polypropylene (PP), Metallized	3 mOhms	-55°C ~ 105°C	Through Hole	2.264 L x 2.756 W (57.50mm x 70.00mm)	2.559 (65.00mm)	PC Pins	2.067 (52.50mm)	DC Link, DC Filtering	-
MKP1848C71680JY5 CAP FILM 160UF 5% 800VDC RADIAL Vishay Beyschlag/Draloric/BC Components	3,382	57.72	RFQ	Datasheet	Radial - 4 Leads	Bulk	MKP1848C DC-Link	Active	160 µF	±5%	-	800V	Polypropylene (PP), Metallized	2.5 mOhms	-55°C ~ 105°C	Through Hole	2.264 L x 2.756 W (57.50mm x 70.00mm)	2.559 (65.00mm)	PC Pins	2.067 (52.50mm)	DC Link, DC Filtering	-
B25631A1117K000 CAP FILM 110UF 10% 1KVDC RADIAL EPCOS - TDK Electronics	1,669	57.76	RFQ	Datasheet	Radial, Can	Bulk	LSI	Not For New Designs	110 µF	±10%	-	1000V (1kV)	Polypropylene (PP), Metallized	-	-55°C ~ 70°C	Chassis Mount	3.346 Dia (85.00mm)	2.598 (66.00mm)	Threaded, Male	1.772 (45.00mm)	DC Link, DC Filtering	-
SNU202K504R-F CAP FILM 0.5UF 10% 2KVPK RADIAL Cornell Dubilier Electronics (CDE)	1,199	57.77	RFQ	Datasheet	Radial, Can	Bulk	SNU	Active	0.5 µF	±10%	2000Vpk (2KVPK)	-	Paper, Metallized	-	-50°C ~ 70°C	Chassis Mount	2.100 L x 1.810 W (53.34mm x 45.97mm)	2.880 (73.15mm)	Solder Lug	0.810 (20.57mm)	High Pulse, DV/DT; Snubber	-
SNU102K105R-F CAP FILM 1UF 10% 1KVPK RADIAL Cornell Dubilier Electronics (CDE)	3,987	57.95	RFQ	Datasheet	Radial, Can	Bulk	SNU	Active	1 µF	±10%	1000Vpk (1KVPK)	-	Paper, Metallized	-	-50°C ~ 70°C	Chassis Mount	2.100 L x 1.810 W (53.34mm x 45.97mm)	2.134 (54.20mm)	Solder Lug	0.810 (20.57mm)	High Pulse, DV/DT; Snubber	-
B32373B5806J030 CAP FILM 80UF 5% 1.35KVDC RADIAL EPCOS - TDK Electronics	3,339	57.98	RFQ		Radial, Can	Bulk	MKD AC - Single Phase	Active	80 µF	±5%	530V	1350V (1.35kV)	Polypropylene (PP), Metallized	-	-40°C ~ 70°C	Chassis, Stud Mount	3.346 Dia (85.00mm)	5.689 (144.50mm)	Threaded, Male	1.378 (35.00mm)	General Purpose	-
B32362B2337J050 CAP FILM 330UF 5% 250VAC RADIAL EPCOS - TDK Electronics	3,737	58.27	RFQ		Radial, Can	Bulk	MKP AC	Active	330 µF	±5%	250V	-	Polypropylene (PP), Metallized	-	-40°C ~ 70°C	Chassis Mount	-	-	Threaded, Male	1.378 (35.00mm)	General Purpose	-
B32362A4157J080 CAP FILM 150UF 5% 480VAC RADIAL EPCOS - TDK Electronics	3,666	58.91	RFQ	Datasheet	Radial, Can	Bulk	MKP AC	Active	150 µF	±5%	480V	-	Polypropylene (PP), Metallized	-	-40°C ~ 70°C	Chassis, Stud Mount	3.346 Dia (85.00mm)	7.756 (197.00mm)	Threaded, Male	1.378 (35.00mm)	General Purpose	-
SFD44T55K391B-F CAP FILM 55UF 10% 440VAC RADIAL Cornell Dubilier Electronics (CDE)	2,122	59.38	RFQ	Datasheet	Radial, Can	Bulk	SF	Active	55 µF	±10%	440V	-	Polypropylene (PP), Metallized	-	-40°C ~ 70°C	Chassis Mount, Requires Holder/Bracket	3.660 L x 1.970 W (92.96mm x 50.04mm), Lip	4.030 (102.36mm)	Quick Connect, Disconnect	0.810 (20.57mm)	Motor Run	-
T10W4NR-F CAP FILM 4UF 10% 1KVDC RADIAL Cornell Dubilier Electronics (CDE)	2,613	59.49	RFQ	Datasheet	Radial, Can	Bulk	T	Active	4 µF	±10%	-	1000V (1kV)	Paper, Metallized	-	-55°C ~ 105°C	Chassis Mount, Requires Holder/Bracket	2.160 L x 1.310 W (54.86mm x 33.27mm), Lip	4.310 (109.47mm)	Threaded, Male	0.810 (20.57mm)	EMI, RFI Suppression	-
