| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Inputs-Side1/Side2 | Voltage-Isolation | CommonModeTransientImmunity(Min) | InputType | OutputType | Current-Output/Channel | DataRate | PropagationDelaytpLH/tpHL(Max) | Rise/FallTime(Typ) | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ACPL-2670L-100OPTOISO 1.5KV 2CH OPEN COL 16DIP |
4,869 | 94.71 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
ACPL-2670L-200OPTOISO 1.5KV 2CH OPEN COL 16DIP |
4,808 | 94.71 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
ACPL-5630LOPTOISO 1.5KV 2CH OPEN COLL 8DIP |
4,432 | 96.42 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
ACPL-5630L-100OPTOISO 1.5KV 2CH OPEN COLL 8SMD |
2,738 | 96.83 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
ACPL-5630L-200OPTOISO 1.5KV 2CH OPEN COLL 8DIP |
3,393 | 96.83 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
HCPL-5400#100OPTOISO 1.5KV TRI-STATE 8SMD |
3,753 | 97.97 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | -55°C ~ 125°C | Surface Mount |
|
|
HCPL-5400#200OPTOISO 1.5KV TRI-STATE 8DIP |
3,586 | 97.97 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | -55°C ~ 125°C | Through Hole |
|
ACPL-5630L-300OPTOISO 1.5KV OPEN COLL 8DIP GW |
1,670 | 98.05 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
ACPL-2670L-300OPTOISO 1.5KV 2CH OPEN COL 16DIP |
4,593 | 98.59 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
6N134/883B#300OPTOISO 1.5KV OPEN COLL 16DIP GW |
4,958 | 99.15 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.55V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
8102801TAOPTOISO 1.5KV OPEN COLL 16SMD GW |
2,008 | 99.15 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 35ns, 35ns | 1.55V | 20mA | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
HCPL-5400#300OPTOISO 1.5KV TRI-STATE 8DIP GW |
2,169 | 99.19 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 1500VDC | 500V/µs | DC | Tri-State | 25 mA | 40Mbps | 60ns, 60ns | 15ns, 10ns | 1.35V | 10mA | 4.75V ~ 5.25V | -55°C ~ 125°C | Surface Mount |
|
|
ACPL-2672LOPTOISO 1.5KV 2CH OPEN COL 16DIP |
829 | 100.51 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
5962-0824203HECOPTOISO 1.5KV 2CH OPN COLL 16DIP |
721 | 100.51 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
ACPL-2672L-100OPTOISO 1.5KV 2CH OPEN COL 16DIP |
821 | 100.88 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
ACPL-2672L-200OPTOISO 1.5KV 2CH OPEN COL 16DIP |
940 | 100.88 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
5962-0824203HEAOPTOISO 1.5KV 2CH OPN COLL 16DIP |
537 | 100.88 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Through Hole |
|
|
5962-0824203HUCOPTOISO 1.5KV 2CH OPN COLL 16SMD |
965 | 100.88 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
5962-0824203HUAOPTOISO 1.5KV 2CH OPN COLL 16SMD |
816 | 101.26 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10MBd | 100ns, 100ns | 20ns, 8ns | 1.55V | 20mA | 3V ~ 3.6V | -55°C ~ 125°C | Surface Mount |
|
|
HCPL-5300#200OPTOISO 1.5KV OPN COLLECTOR 8DIP |
887 | 101.30 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 1500VDC | 10kV/µs (Typ) | DC | Open Collector, Schottky Clamped | 15 mA | - | 750ns, 500ns | - | 1.5V | 25mA | 4.5V ~ 30V | -55°C ~ 125°C | Through Hole |
