Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	TransformerType	Inductance	ET(Volt-Time)	TurnsRatio-Primary:Secondary	MountingType	Size/Dimension	Height-Seated(Max)
PA2649NLT PULSE XFMR 100.5UH Pulse Electronics Power	6,126	4.00	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	-	100.5µH	-	-	Surface Mount	0.551 L x 0.516 W (14.00mm x 13.11mm)	0.485 (12.32mm)
PA1276NLT XFRMR 12V 13.5W 77.4UH POE EP13 Pulse Electronics Power	8,901	4.00	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EP13	Active	Isolation and Data Interface (Encapsulated)	77.4µH	-	1:0.682:0.682	Surface Mount	0.551 L x 0.695 W (14.00mm x 17.65mm)	0.500 (12.70mm)
PA1135NLT XFRMR 12V 7W 264UH POE EP10 SMD Pulse Electronics Power	6,129	4.09	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EP10	Active	Isolation and Data Interface (Encapsulated)	264.1µH	-	1:0.286:0.204	Surface Mount	0.515 L x 0.600 W (13.08mm x 15.24mm)	0.451 (11.45mm)
PA1283NLT XFRMR 5V 7W 155UH POE EP10 SMD Pulse Electronics Power	8,941	4.09	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EP10	Active	Isolation and Data Interface (Encapsulated)	155µH	-	1:0.273:0.682	Surface Mount	0.515 L x 0.600 W (13.08mm x 15.24mm)	0.451 (11.45mm)
PA1260NLT XFRMR 5V 13.5W 77.4UH POE EP13 Pulse Electronics Power	6,319	4.10	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EP13	Active	Isolation and Data Interface (Encapsulated)	77.4µH	-	1:0.273:0.682	Surface Mount	0.551 L x 0.516 W (14.00mm x 13.11mm)	0.485 (12.32mm)
SPOE3-0508 POE POWER OVER ETHERNET EP7 CORE Signal Transformer	9,772	4.35	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	SPoE	Active	Power over Ethernet (PoE)	500µH	-	1:00.1	Surface Mount	-	-
B82804A0694A115 PULSE XFMR 1.5:1 690UH EPCOS - TDK Electronics	9,905	4.52	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EP5	Active	Gate Drive	690µH	40.8VµS	1.5:1	Surface Mount	0.264 L x 0.240 W (6.70mm x 6.10mm)	0.213 (5.40mm)
B82804A0324A220 PULSE XFMR 2:1:1 317UH EPCOS - TDK Electronics	5,208	4.52	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	EP5	Active	Gate Drive	317µH	24.5VµS	2:1:1	Surface Mount	0.264 L x 0.240 W (6.70mm x 6.10mm)	0.213 (5.40mm)
PA2004NL PULSE XFMR 1:1:1 437UH Pulse Electronics Power	6,325	2.64	RFQ	Datasheet	Tube	-	Active	-	437µH	20VµS	1:1:1	Surface Mount	0.340 L x 0.265 W (8.64mm x 6.73mm)	0.140 (3.56mm)
PH9185.043NLT TRANSFORMER 1260UH 4:3 SMD Pulse Electronics Power	6,001	4.55	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PH9185	Active	-	-	-	-	Surface Mount	0.394 L x 0.394 W (10.00mm x 10.00mm)	0.492 (12.50mm)
PE-65728NLT TRANSFORMER 2000VRMS 100UH SMD Pulse Electronics Network	6,030	5.30	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Isolation and Data Interface (Encapsulated)	100µH	1.8VµS	1:1	Surface Mount	0.500 L x 0.285 W (12.70mm x 7.24mm)	0.210 (5.33mm)
SM91047EL PULSE XFMR 11.875:1 5MH Bourns Inc.	7,148	5.15	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	-	5mH	-	11.875:1	Surface Mount	0.531 L x 0.701 W (13.50mm x 17.80mm)	0.500 (12.70mm)
HX2260FNLT PULSE XFMR 1 CT:1CT TX/RX 350UH Pulse Electronics Network	7,649	5.49	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	LAN 10/100 Base-T	350µH	-	1CT:1CT Transmitter, 1CT:1CT Receiver	Surface Mount	0.500 L x 0.358 W (12.70mm x 9.09mm)	0.236 (5.99mm)
H1197FNLT PULSE XFMR 1CT:1CT TX 1CT:1CT RX Pulse Electronics Network	6,805	5.07	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	LAN 10/100 Base-T	1.2mH	-	1CT:1CT Transmitter, 1CT:1CT Receiver	Surface Mount	0.500 L x 0.358 W (12.70mm x 9.09mm)	0.236 (5.99mm)
750510682 DIGITAL TRANSFORMER Würth Elektronik	6,075	3.96	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	-	1µH	-	1:1	Surface Mount	-	0.520 (13.20mm)
T1090NLT XFRMR 1CT:2CT/1CT:2CT 1.2/1.2MH Pulse Electronics Network	9,963	5.52	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	T1/E1 (Dual)	1.2mH, 1.2mH	-	1CT:2CT, 1CT:2CT	Surface Mount	0.505 L x 0.280 W (12.83mm x 7.11mm)	0.245 (6.22mm)
T1137NLT XFRMR 1CT:2.42CT/1CT:2.42CT SMD Pulse Electronics Network	6,592	5.52	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	T1/E1 (Dual)	1.2mH, 1.2mH	-	1CT:2.42CT, 1CT:2.42CT	Surface Mount	0.505 L x 0.280 W (12.83mm x 7.11mm)	0.245 (6.22mm)
TX1099NLT XFRMR 1CT:1:0.8/1CT:1:0.8 SMD Pulse Electronics Network	8,069	5.52	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	T1/E1 (Dual)	1.2mH, 1.2mH	-	1CT:1:0.8, 1CT:1:0.8	Surface Mount	0.505 L x 0.280 W (12.83mm x 7.11mm)	0.245 (6.22mm)
IL-11-0002 IL1 PULSE TRANSFORMER THT 0.25A SCHURTER Inc.	5,569	3.34	RFQ	Datasheet	Bulk	IL	Active	Isolation and Data Interface (Encapsulated)	2.5mH	-	1:1	Through Hole	0.689 L x 0.728 W (17.50mm x 18.50mm)	0.453 (11.50mm)
PA2531NL PULSE XFMR 4.5UH Pulse Electronics Power	8,639	3.37	RFQ	Datasheet	Tray	-	Active	-	4.5µH	-	-	Through Hole	0.717 L x 0.630 W (18.20mm x 16.00mm)	0.709 (18.00mm)
