Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	DrivenConfiguration	ChannelType	NumberofDrivers	GateType	Voltage-Supply	LogicVoltage-VILVIH	Current-PeakOutput(SourceSink)	InputType	HighSideVoltage-Max(Bootstrap)	Rise/FallTime(Typ)	OperatingTemperature	MountingType
LTC1154CS8#TRPBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	5,067	6.77	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	High-Side	Single	1	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	-	Non-Inverting	-	-	0°C ~ 70°C (TA)	Surface Mount
LTC4442EMS8E#PBF IC GATE DRVR HALF-BRIDGE 8MSOP Analog Devices Inc.	5,599	4.33	FFQ	Datasheet	Tube	-	Active	Half-Bridge	Synchronous	2	N-Channel MOSFET	6V ~ 9.5V	-	2.4A, 2.4A	Non-Inverting	42 V	12ns, 8ns	-40°C ~ 125°C (TJ)	Surface Mount
LTC1255CS8#TRPBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	9,582	9.66	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	High-Side	Independent	2	N-Channel MOSFET	9V ~ 24V	0.8V, 2V	-	Non-Inverting	-	-	0°C ~ 70°C (TA)	Surface Mount
LTC4440EMS8E#PBF IC GATE DRVR HIGH-SIDE 8MSOP Analog Devices Inc.	6,463	5.98	FFQ	Datasheet	Tube	-	Active	High-Side	Single	1	N-Channel MOSFET	8V ~ 15V	1.3V, 1.6V	2.4A, 2.4A	Non-Inverting	80 V	10ns, 7ns	-40°C ~ 85°C (TA)	Surface Mount
LTC1154HS8#PBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	9,020	7.47	FFQ	Datasheet	Tube	-	Active	High-Side	Single	1	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	-	Non-Inverting	-	-	-40°C ~ 150°C (TA)	Surface Mount
LTC4444MPMS8E#PBF IC GATE DRVR HALF-BRIDGE 8MSOP Analog Devices Inc.	7,603	8.73	FFQ	Datasheet	Tube	-	Active	Half-Bridge	Independent	2	N-Channel MOSFET	7.2V ~ 13.5V	1.85V, 3.25V	2.5A, 3A	Non-Inverting	114 V	8ns, 5ns	-55°C ~ 150°C (TJ)	Surface Mount
LTC1255CS8#PBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	8,286	9.66	FFQ	Datasheet	Tube	-	Active	High-Side	Independent	2	N-Channel MOSFET	9V ~ 24V	0.8V, 2V	-	Non-Inverting	-	-	0°C ~ 70°C (TA)	Surface Mount
LTC1155CS8#PBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	1,747	10.67	FFQ	Datasheet	Tube	-	Active	High-Side	Independent	2	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	-	Non-Inverting	-	-	0°C ~ 70°C (TA)	Surface Mount
LT1161CSW#PBF IC GATE DRVR HIGH-SIDE 20SOIC Analog Devices Inc.	1,689	11.18	FFQ	Datasheet	Tube	-	Active	High-Side	Independent	4	N-Channel MOSFET	8V ~ 48V	0.8V, 2V	-	Non-Inverting	-	-	0°C ~ 125°C (TJ)	Surface Mount
ADP3624ARHZ-RL IC GATE DRVR LOW-SIDE 8MSOP Analog Devices Inc.	5,926	3.46	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	4A, 4A	Non-Inverting	-	10ns, 10ns	-40°C ~ 150°C (TJ)	Surface Mount
ADP3634ARDZ IC GATE DRVR LOW-SIDE 8SOIC Analog Devices Inc.	8,530	3.15	FFQ	Datasheet	Tube	-	Active	Low-Side	Independent	2	N-Channel MOSFET	9.5V ~ 18V	0.8V, 2V	4A, 4A	Non-Inverting	-	10ns, 10ns	-40°C ~ 150°C (TJ)	Surface Mount
LT1158CN#PBF IC GATE DRVR HALF-BRIDGE 16DIP Analog Devices Inc.	4,892	10.27	FFQ	Datasheet	Tube	-	Active	Half-Bridge	Synchronous	2	N-Channel MOSFET	5V ~ 30V	0.8V, 2V	500mA, 500mA	Inverting, Non-Inverting	56 V	130ns, 120ns	0°C ~ 125°C (TJ)	Through Hole
LT1336IS#PBF IC GATE DRVR HALF-BRIDGE 16SOIC Analog Devices Inc.	2,724	11.53	FFQ	Datasheet	Tube	-	Active	Half-Bridge	Independent	2	N-Channel MOSFET	10V ~ 15V	0.8V, 2V	1.5A, 1.5A	Non-Inverting	60 V	130ns, 60ns	-40°C ~ 125°C (TJ)	Surface Mount
LTC1155IS8#PBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	1,944	12.11	FFQ	Datasheet	Tube	-	Active	High-Side	Independent	2	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	-	Non-Inverting	-	-	-40°C ~ 85°C (TA)	Surface Mount
ADP3624ARHZ IC GATE DRVR LOW-SIDE 8MSOP Analog Devices Inc.	7,887	3.46	FFQ	Datasheet	Tube	-	Active	Low-Side	Independent	2	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	4A, 4A	Non-Inverting	-	10ns, 10ns	-40°C ~ 150°C (TJ)	Surface Mount
LTC4442IMS8E#PBF IC GATE DRVR HALF-BRIDGE 8MSOP Analog Devices Inc.	8,916	4.80	FFQ	Datasheet	Tube	-	Active	Half-Bridge	Synchronous	2	N-Channel MOSFET	6V ~ 9.5V	-	2.4A, 2.4A	Non-Inverting	42 V	12ns, 8ns	-40°C ~ 125°C (TJ)	Surface Mount
LTC4441IS8-1#PBF IC GATE DRVR LOW-SIDE 8SOIC Analog Devices Inc.	7,400	6.83	FFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	N-Channel MOSFET	5V ~ 25V	1.8V, 2V	6A, 6A	Non-Inverting	-	13ns, 8ns	-40°C ~ 125°C (TJ)	Surface Mount
LT8672HMS#PBF IC GATE DRVR HIGH-SIDE 10MSOP Analog Devices Inc.	5,188	7.32	FFQ	Datasheet	Tube	-	Active	High-Side	Single	1	N-Channel MOSFET	3V ~ 42V	-	-	Non-Inverting	-	-	-40°C ~ 150°C (TJ)	Surface Mount
ADP3625ARDZ-RL IC GATE DRVR LOW-SIDE 8SOIC Analog Devices Inc.	5,213	3.15	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Independent	2	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	4A, 4A	Inverting, Non-Inverting	-	10ns, 10ns	-40°C ~ 150°C (TJ)	Surface Mount
LTC1155IS8#TRPBF IC GATE DRVR HIGH-SIDE 8SOIC Analog Devices Inc.	1,352	12.11	FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	High-Side	Independent	2	N-Channel MOSFET	4.5V ~ 18V	0.8V, 2V	-	Non-Inverting	-	-	-40°C ~ 85°C (TA)	Surface Mount
