Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	DrivenConfiguration	ChannelType	NumberofDrivers	GateType	Voltage-Supply	LogicVoltage-VILVIH	Current-PeakOutput(SourceSink)	InputType	HighSideVoltage-Max(Bootstrap)	Rise/FallTime(Typ)	OperatingTemperature	MountingType
HIP5015IS1 HB BASED PERIPHERAL DRIVER W/PWM Harris Corporation	5,105	1.83	RFQ	Datasheet	Bulk	-	Active	Half-Bridge	Synchronous	1	N-Channel MOSFET	9.6V ~ 14.4V	-	5A, 5A	Non-Inverting	-	20ns, 20ns	-40°C ~ 85°C	Through Hole
ISL6612IB HALF BRIDGE BASED MOSFET DRIVER Intersil	3,960	1.85	RFQ	Datasheet	Tube	-	Obsolete	Half-Bridge	Synchronous	2	N-Channel MOSFET	10.8V ~ 13.2V	-	1.25A, 2A	Non-Inverting	36 V	26ns, 18ns	-40°C ~ 125°C (TJ)	Surface Mount
ISL6612ECB HALF BRIDGE BASED MOSFET DRIVER Intersil	2,449	1.85	RFQ	Datasheet	Tube	-	Obsolete	Half-Bridge	Synchronous	2	N-Channel MOSFET	10.8V ~ 13.2V	-	1.25A, 2A	Non-Inverting	36 V	26ns, 18ns	0°C ~ 125°C (TJ)	Surface Mount
ISL89165FBECZ AND GATE BASED MOSFET DRIVER Intersil	2,368	3.26	RFQ	Datasheet	Tube	-	Obsolete	Low-Side	Independent	2	N-Channel MOSFET	7.5V ~ 16V	2.4V, 9.6V	6A, 6A	Inverting, Non-Inverting	-	20ns, 20ns	-40°C ~ 125°C (TJ)	Surface Mount
ISL89160FRTBZ AND GATE BASED MOSFET DRIVER Intersil	2,493	3.26	RFQ	Datasheet	Tube	-	Obsolete	Low-Side	Independent	2	N-Channel MOSFET	4.5V ~ 16V	1.85V, 3.15V	6A, 6A	Non-Inverting	-	20ns, 20ns	-40°C ~ 125°C (TJ)	Surface Mount
HIP2100EIB HALF BRIDGE BASED MOSFET DRIVER Intersil	3,360	3.33	RFQ	Datasheet	Tube	-	Obsolete	Half-Bridge	Independent	2	N-Channel MOSFET	9V ~ 14V	4V, 7V	2A, 2A	Non-Inverting	114 V	10ns, 10ns	-55°C ~ 150°C (TJ)	Surface Mount
IRS2332SPBF MOSFET DRIVER, PDSO28 International Rectifier	6,339	3.35	RFQ	Datasheet	Bulk	-	Active	Half-Bridge	3-Phase	6	IGBT, N-Channel MOSFET	10V ~ 20V	0.8V, 2.2V	250mA, 500mA	Inverting	600 V	80ns, 35ns	-40°C ~ 150°C (TJ)	Surface Mount
MCP14A0301T-E/KBA IC GATE DRVR HI/LOW SIDE 8WDFN Microchip Technology	6,381	1.05	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	High-Side or Low-Side	Single	1	IGBT	4.5V ~ 18V	0.8V, 2V	3A, 3A	Inverting, Non-Inverting	-	13ns, 12ns	-40°C ~ 125°C (TA)	Surface Mount, Wettable Flank
TCK420G,L3F LOAD SWITCH (GATE DRIVER) IC WCS Toshiba Semiconductor and Storage	10,458	0.87	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	High-Side	Single	1	N-Channel MOSFET	2.7V ~ 28V	0.4V, 1.2V	-	Non-Inverting	-	-	-40°C ~ 85°C	Surface Mount
TCK421G,L3F GATE DRIVER IC VIN:2.7-28V OVLO Toshiba Semiconductor and Storage	14,155	0.87	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	High-Side and Low-Side	Synchronous	2	N-Channel MOSFET	2.7V ~ 28V	0.4V, 1.2V	-	Non-Inverting	-	-	-40°C ~ 85°C (TA)	Surface Mount
NCP51100ASNT1G SINGLE 2 A HIGH-SPEED, LOW-SIDE onsemi	14,402	0.87	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Low-Side	Single	1	IGBT, N-Channel MOSFET	11V ~ 18V	2V, 0.8V	3A, 3A	Non-Inverting	-	14ns, 7ns	-40°C ~ 125°C (TA)	Surface Mount
NCP81253MNTBG IC GATE DRVR HALF-BRIDGE 8DFN onsemi	14,543	0.91	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Half-Bridge	Synchronous	2	N-Channel MOSFET	4.5V ~ 5.5V	0.7V, 3.4V	-	Non-Inverting	35 V	16ns, 11ns	-40°C ~ 150°C (TJ)	Surface Mount
TC4431CPA IC GATE DRV HI-SIDE/LO-SIDE 8DIP Microchip Technology	7,887	3.98	RFQ	Datasheet	Tube	-	Active	High-Side or Low-Side	Single	1	N-Channel, P-Channel MOSFET	4.5V ~ 30V	0.8V, 2.4V	1.5A, 1.5A	Inverting	-	25ns, 33ns	0°C ~ 150°C (TJ)	Through Hole
TC4432CPA IC GATE DRV HI-SIDE/LO-SIDE 8DIP Microchip Technology	5,296	3.98	RFQ	Datasheet	Tube	-	Active	High-Side or Low-Side	Single	1	N-Channel, P-Channel MOSFET	4.5V ~ 30V	0.8V, 2.4V	1.5A, 1.5A	Non-Inverting	-	25ns, 33ns	0°C ~ 150°C (TJ)	Through Hole
TC4420CAT IC GATE DRVR LOW-SIDE TO220-5 Microchip Technology	7,816	3.99	RFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	N-Channel, P-Channel MOSFET	4.5V ~ 18V	0.8V, 2.4V	6A, 6A	Non-Inverting	-	25ns, 25ns	0°C ~ 150°C (TJ)	Through Hole
IR2183SPBF IC GATE DRVR HALF-BRIDGE 8SOIC Infineon Technologies	8,194	4.02	RFQ	Datasheet	Tube	-	Active	Half-Bridge	Independent	2	IGBT, N-Channel MOSFET	10V ~ 20V	0.8V, 2.7V	1.9A, 2.3A	Inverting, Non-Inverting	600 V	40ns, 20ns	-40°C ~ 150°C (TJ)	Surface Mount
TC4422CPA IC GATE DRVR LOW-SIDE 8DIP Microchip Technology	7,523	4.19	RFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 18V	0.8V, 2.4V	9A, 9A	Non-Inverting	-	60ns, 60ns	0°C ~ 150°C (TJ)	Through Hole
TC4432EPA IC GATE DRV HI-SIDE/LO-SIDE 8DIP Microchip Technology	8,035	4.19	RFQ	Datasheet	Tube	-	Active	High-Side or Low-Side	Single	1	N-Channel, P-Channel MOSFET	4.5V ~ 30V	0.8V, 2.4V	1.5A, 1.5A	Non-Inverting	-	25ns, 33ns	-40°C ~ 150°C (TJ)	Through Hole
TC4421CPA IC GATE DRVR LOW-SIDE 8DIP Microchip Technology	7,604	4.19	RFQ	Datasheet	Tube	-	Active	Low-Side	Single	1	IGBT, N-Channel, P-Channel MOSFET	4.5V ~ 18V	0.8V, 2.4V	9A, 9A	Inverting	-	60ns, 60ns	0°C ~ 150°C (TJ)	Through Hole
LTC4442IMS8E#PBF IC GATE DRVR HALF-BRIDGE 8MSOP Analog Devices Inc.	8,916	4.80	RFQ	Datasheet	Tube	-	Active	Half-Bridge	Synchronous	2	N-Channel MOSFET	6V ~ 9.5V	-	2.4A, 2.4A	Non-Inverting	42 V	12ns, 8ns	-40°C ~ 125°C (TJ)	Surface Mount
