Results:

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
E20/10/6-3C90-A200 E CORES Ferroxcube	14,611	0.20	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C90-A250 E CORES Ferroxcube	11,869	0.20	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C90-A315 E CORES Ferroxcube	10,510	0.20	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C90-G250 E CORES Ferroxcube	11,945	0.20	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C90-G400 E CORES Ferroxcube	13,197	0.20	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C94-G100 E CORES Ferroxcube	10,148	0.20	RFQ	Datasheet	Bulk	-	Active	E	E 20 x 10 x 6	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C94-G200 E CORES Ferroxcube	11,150	0.20	RFQ	Datasheet	Bulk	-	Active	E	E 20 x 10 x 6	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E16/12/5-3C92 E CORES Ferroxcube	10,308	0.20	RFQ	Datasheet	Bulk	-	Active	E	E 16 x 12 x 5	3C92	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.482 (12.25mm)
35T0501-00H FT,MNZN,EC 12.70X7.14X4.78-5000 Laird-Signal Integrity Products	13,088	0.21	RFQ	Datasheet	Bulk	-	Active	Toroid	-	35	0.506 (12.85mm)	2.75 µH	±20%	Ungapped	-	5000	2.09	29.32	14.01	-	-	Epoxy	0.194 (4.93mm)
35T0500-00H FT,MNZN,EC 12.70X7.92X3.18-5000 Laird-Signal Integrity Products	14,516	0.21	RFQ	Datasheet	Bulk	-	Active	Toroid	-	35	0.506 (12.85mm)	1.5 µH	±20%	Ungapped	-	5000	3.75	31.06	8.28	-	-	Epoxy	0.131 (3.33mm)
B62152A0008X046 FERRITE CORE EPCOS - TDK Electronics	13,316	0.21	RFQ		Box	MHB2-2.5/3.6/2.1	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B64290A0044X830 FERRITE CORE TOROID 2.2UH N30 EPCOS - TDK Electronics	13,033	0.21	RFQ	Datasheet	Box	T12.5/7.5/5	Active	Toroid	R 12.5 x 7.5 x 5	N30	0.492 (12.50mm)	2.2 µH	±25%	Ungapped	-	4300	2.46	30.09	12.23	-	368	Uncoated	0.197 (5.00mm)
B64290A0047X830 FERRITE CORE EPCOS - TDK Electronics	10,217	0.21	RFQ	Datasheet	Box	T12.5/7.5/5	Active	Toroid	-	-	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	-
B66305G0000X165 FERRITE CORE EPCOS - TDK Electronics	11,988	0.21	RFQ	Datasheet	Box	E13/7/4	Active	E	E 13 x 7 x 4	T65	-	1.3 µH	±30%	Ungapped	2470	5200	2.39	29.6	12.4	12.2	367	Uncoated	0.256 (6.50mm)
E20/10/6-3C92 E CORES Ferroxcube	14,288	0.21	RFQ	Datasheet	Bulk	-	Active	E	E 20 x 10 x 6	3C92	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
B62110A1016X022 FERRITE CORES EPCOS - TDK Electronics	10,476	0.21	RFQ		Box	TUB1.84/0.8/3.4	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B66305U0250M127 FERRITE CORE EPCOS - TDK Electronics	14,518	0.21	RFQ		Box	E13/7/4	Active	E	E 13 x 7 x 4	N27	-	-	-	Gapped	-	2000	2.39	29.6	12.4	12.2	367	Uncoated	0.256 (6.50mm)
E20/10/6-3C90-G1000 E CORES Ferroxcube	11,161	0.21	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C90-G500 E CORES Ferroxcube	12,251	0.21	RFQ		Bulk	-	Active	E	E 20 x 10 x 6	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
E20/10/6-3C96 E CORES Ferroxcube	12,773	0.21	RFQ	Datasheet	Bulk	-	Active	E	E 20 x 10 x 6	3C96	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.402 (10.20mm)
